SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

Name: SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet
Brand: MITTEL
Price: 1.2 USD

Buy cheap SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet product

Brand Name : MITTEL

Model Number : ASTM A387

Certification : ISO MTC SGS

Place of Origin : China

MOQ : 500KGS

Price : 1.2 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 5000Ton

Delivery Time : 7 Days

Packaging Details : Wodden Pallet

Application : Boiler Plate

Technique : Hot Rolled

Type : Steel Plate

Width : 600mm-1250mm,2000-2300mm

Special use : Alloy structual steel

Grade : alloy steel plate

Thickness : 2-100mm

Material : Alloy Structual Steel

Price term : CIF CFR FOB EX-WORK

Contact Now

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

ASTM A387 GRADE 11 Class 2

As a pressure vessel grade steel for use in elevated temperature service, is used in a variety of industries and is highly effective, particularly in the oil, gas and petrochemical industry, where liquids and gases are often stored at higher temperatures.

The higher levels of chromium also provide excellent corrosion and oxidation resistance, which is a must in sour gas applications. Please refer to our technical specifications below for ASTM A387 Grade 11 Class 2...

Equivalents

BS	EN	ASTM/ASME	DIN
621 B	–––	A387-11-2	–––

Specifications for ASTM A387 Grade 11 Alloy Steel Plates

Chromium & Molybdenum content (according to the ASME specification)

Designation	Nominal Chromium Content (%)	Nominal Molybdenum Content (%)
A387 Grade 11	1.25%	0.50%

Tensile Requirements for ASTM A387 Grade 11 Alloy Steel Plates Class 1 Plates

Designation:	Requirement:	Grade 11
A387 Grade 11	Tensile strength, ksi [MPa]	75 to 100 [515 to 690]
	Yield strength, min, ksi [MPa]/(0.2% offset)	43 [310]
	Elongation in 8 in. [200mm], min %	18
	Elongation in 2 in. [50mm], min, %	22
	Reduction of area, min %	–––

Chemical Requirements for ASTM A387 Grade 11 Alloy Steel Plates

Element		Chemical Composition (%)
		A387 Grade 11
Carbon:	Heat Analysis:	0.05 - 0.17
	Product Analysis:	0.04 - 0.17
Manganese:	Heat Analysis:	0.40 - 0.65
	Product Analysis:	0.35 - 0.73
Phosphorus:	Heat Analysis:	0.035
	Product Analysis:	0.035
Sulphur (max):	Heat Analysis:	0.035
	Product Analysis:	0.035
Silicon:	Heat Analysis:	0.50 - 0.80
	Product Analysis:	0.44 - 0.86
Chromium:	Heat Analysis:	1.00 - 1.50
	Product Analysis:	0.94 - 1.56
Molybdenum:	Heat Analysis:	0.45 - 0.65
	Product Analysis:	0.45 - 0.70

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet
